Page 20 MDE-5412C Passport® EDGE Installation and Start-up Manual · February 2019
VeriFone® MX915 PIN Pad
Passport Customer Display
The Passport customer display will connect to the SZR using a Serial to IP Adapter. The
Adapter connects to the customer display using a connection point on the left-hand side and to
the SZR using a connection point on the right-hand side of the adapter (see Figure 11 on
page 21).
Note: The customer display is currently required only f
or Shell and/or BP locations but maybe
required in other locations based on local requirements.
30T-8- FRONT-EDGE-BASIC
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 PayDev PIN Pad 1
6 Auxiliary Receipt Printer 1
7 Auxiliary Customer Display 1
8 PayDev Dispensers
34T-16-FRONT-EDGE-CD-BASIC
Port V-LAN Segment DEVICE
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 POS PIN Pad 1
6 Auxiliary Receipt Printer 1
7 Auxiliary Customer Display 1
8 Not Used Not Used
9 Auxiliary Tablet 2
10 PayDev PIN Pad 2
11 Auxiliary Receipt Printer 2
12 Auxiliary Customer Display 2
13 Auxiliary Applause
14 PayDev Dispensers
15 Not Used Not Used
16 Not Used Not Used
