Page 64 MDE-5412C Passport® EDGE Installation and Start-up Manual · February 2019
Passport Edge Software Setup
The Internet Protocol Version 4 (TCP/IPv4) dialog box opens (see Figure 92).
Note: Record your current settings in this screen, so that after configuring the
IP to Serial
Adapter, you can return your laptop to original settings.
6 Configure the laptop/PC with the following IP settings (see Figure 92).
Figure 92: Internet Protocol Version 4 (TCP/IPv4) Dialog Box
Field Description
IP address 192.168.0.1
Subnet mask 255.255.255.0
Default gateway N/A
7 On the laptop/PC, open Internet Explorer
®
or Google
™
Chrome and enter 192.168.0.7 in the
address bar.
Figure 93: Entering Address
