MDE-5412C Passport® EDGE Installation and Start-up Manual · February 2019 Page 7
Passport EDGE Hardware Setup
The following are the templates for a single client setup (8-Port):
30T-8-FRONT-EDGE-BASIC
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 PayDev PIN Pad 1
6 Auxiliary Receipt Printer 1
7 Auxiliary Applause Media System
8 PayDev Dispensers
31T-8-FRONT-EDGE-PAYMENT
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 PayDev PIN Pad 1
6 Auxiliary Receipt Printer 1
7 PaymentZone Payment
8 PayDev Dispensers
32T-8-FRONT-EDGE-PAYMENT-TRUNK
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 PayDev PIN Pad 1
6 Auxiliary Receipt Printer 1
7 PaymentZone Payment
8 Switch (Trunk) OUT To another switch
33T-8-BACK-EDGE-CRIND-AUX
Port V-LAN Segment Device
1 Switch (Trunk) IN From front/another switch
2 PayDev CRIND
3 PayDev CRIND
4 PayDev CRIND
5 PayDev CRIND
6 PayDev CRIND
7 PayDev CRIND
8 Auxiliary Applause
