Page 8 MDE-5412C Passport® EDGE Installation and Start-up Manual · February 2019
Passport EDGE Hardware Setup
The following templates are for a dual client setup (16-Port):
34T-16-FRONT-EDGE-BASIC
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 POS PIN Pad 1
6 Auxiliary Receipt Printer 1
7 Not Used Not Used
8 Auxiliary Tablet 2
9 PayDev PIN Pad 2
10 Auxiliary Receipt Printer 2
11 Auxiliary Applause
12 PayDev Dispensers
13 Not Used Not Used
14 Not Used Not Used
15 Not Used Not Used
16 Not Used Not Used
35T-16-FRONT-EDGE-PAYMENT
Port V-LAN Segment Device
1 Switch (Trunk) IN MG
2 EDH EDH
3 POS TPOS (Server)
4 Auxiliary Tablet 1
5 PayDev PIN PAD 1
6 Auxiliary Receipt Printer 1
7 Payment PAYMENT
8 Auxiliary Tablet 2
9 PayDev PIN Pad 2
10 Auxiliary Receipt Printer 2
11 Auxiliary APPLAUSE
12 PayDev Dispensers
13 Not Used Not Used
14 Not Used Not Used
15 Not Used Not Used
16 Not Used Not Used
