Rear wheel pressure (driver and gear)
2 bar
03_04
Spark plug dismantlement (03_04)
Detach the spark plug cap, shown in the figure, and remove the spark plug using the
box-spanner provided. Upon refitting, engage the park plug thread at the correct angle
and screw it in by hand, using the box-spanner for tightening. Then reattach the cap.
CAUTION
FOLLOW THESE PROCEDURES VERY CAREFULLY TO AVOID ANY SEVERE
DAMAGE THAT MAY BE CAUSED BY THE VERY POWERFUL IGNITION SYS-
TEM.
CAUTION
THE SPARK PLUG MUST BE REMOVED WHEN THE ENGINE IS COLD.
USING IGNITION ELECTRONIC CENTRAL UNITS OR SPARK PLUGS OTHER
THAN THE TYPES PRESCRIBED (SEE «TECHNICAL DATA» SECTION) CAN
CAUSE SERIOUS DAMAGE TO THE ENGINE.
Characteristic
Spark plug
CHAMPION RN1C
Electrode distance
0,45 ÷ 055 mm
30
