03_15
Rear optical unit (03_15)
N.B.
IF MISTING IS NOTICED ON THE INSIDE OF THE HEADLAMP GLASS, THIS
DOES NOT INDICATE A FAULT AND IS RELATED TO THE HUMIDITY AND/OR
TO LOW TEMPERATURES.
THE PHENOMENON SHOULD QUICKLY DISAPPEAR WHEN THE LIGHT IS
SWITCHED ON.
THE PRESENCE OF DROPS OF WATER, ON THE OTHER HAND, COULD INDI-
CATE THAT WATER IS INFILTRATING. CONTACT THE PIAGGIO AFTER-SALES
SERVICE NETWORK.
03_16
Rear-view mirrors (03_16)
The mirrors must be adjusted so that the shafts are perpendicular to the vehicle's
direction axis.
To adjust the mirror opening angle loosen the screw fitted at the end of the shaft and
fasten it once the desired position is reached.
41
