Authorised Service Centre. The coolant level must be checked, with the engine cold,
every 5,000 Km, observing the following procedures if top-up is required.
a) Rest the vehicle onto its centre-stand.
b) Insert the key into the lock, turn it anticlockwise and tilt the helmet bay door forward.
Secure the door with the prop located inside the helmet bay, on the left hand side.
c) Remove the expansion tank filler cap "A" by turning anti-clockwise.
d) Remove the expansion tank cover.
e) Top up with fresh coolant if the level is not above the min mark. The coolant level
must always be kept between the min and max marks, identified by the visual refer-
ences stamped onto the tank. The tank is fitted with a plastic cover which is detached
when the filler cap is removed. Upon refitting, ensure the cover snap lips engage cor-
rectly against the helmet bay cover, and refit the filler cap carefully, so as to keep it in
place.
If the coolant level approaches the min mark, top it up with the engine cold. If frequent
top-ups are necessary, or if the expansion tank is found to be completely empty, the
cause of the problem is due to a fault within the cooling system which must be fixed.
The cooling system must therefore be inspected by an Authorised Piaggio-Gilera
Service Station. The coolant must be replaced every 2 years. For this operation,
contact of an Authorised Piaggio-Gilera Service Station.
WARNING
TO AVOID THE RISK OF SCALDING, DO NOT UNSCREW THE EXPANSION
TANK COVER WHILE THE ENGINE IS STILL HOT.
CAUTION
IN ORDER TO AVOID HARMFUL FLUID LEAKS WHILE DRIVING, IT IS IMPOR-
TANT TO MAKE SURE THAT THE LEVEL NEVER EXCEEDS THE MAXIMUM
VALUE.
32
