FUSE CHART
Fuse No. 1 Position on fuse box: 1
Capacity: 20A
Protected circuits: System
protection main fuse
Location: battery compartment
Fuse No. 2 Position on fuse box: 2
Capacity: 7.5 A
Protected circuits: High and low
beam light bulbs.
Location: battery compartment
Fuse No. 3 Position on fuse box: 3
Capacity: 7.5 A
Protected circuits: Stop light
bulbs, engine start-up control,
horn, instrument panel
Location: battery compartment
Fuse No. 4 Position on fuse box: 4
Capacity: 3A
Protected circuits: Front and rear
tail light bulbs and license plate
light
Location: battery compartment
51
