Rear tail light bulb Type: All glass
Power: 12V - 3W
Quantity: 2
03_26
03_27
Front light group (03_26, 03_27, 03_28)
In order to reach the headlamp bulb remove the snap-on Gilera shield, located on the
front shield, by inserting the blade of a small screwdriver in the corresponding lateral
notch, being careful not to scratch the paint. Then loosen the screw «A» underneath
and lift up the front shield centre cover.
Then follow this procedure:
High and low beam bulb:
1. remove the rubber cover «B», take hold of the bulb holder and rotate it up-
wards by 30°;
2. disconnect the bulb connector and change the bulb.
Tail lights:
1. remove the rubber bulb holder «C» from its housing, then remove the bulb
and replace it.
53
