Gill Instruments Ltd
Intrinsically Safe WindObserver Anemometer Page 45 Issue 10
Doc. No. 1360-PS-0001 May 2015
Dx- Diagnostic and Configuration Command
Each of these commands causes a response from the Intrinsically Safe WindObserver.
Item
Command
code
Typical response
Type and serial No.
D1
I
0
3000
Software version
D2
1.0
3
2
Unit configuration
D3
Current configuration:
B3 F1 G0000 K1 L1 M2 NA O1 P1 U1 V1 X1
Anemometer
power supply
voltage
D5 +07.9
Integrity check
D6
See Para 10.6 Bench Tests
Fx- Data and Parity Options
Setting
Configuration code
8 bits, no parity, 1 stop bit
F1
8 bits, even parity, 1 stop bit
F2
8 bits, odd parity, 1 stop bit
F3
Gx to Gxxxx - Averaging
Setting
Configuration code
No
Averaging (Default)
G0000
Enter the required averaging period in seconds as a four figure number between 0000 and
3600.
If for example set for G0005 then there will be a single output once every 5 seconds
based on the average of the previous five once second results.
Kx – NMEA Settings
Setting
Configuration code
NMEA string “IIMWV”
K1
NMEA string “WIMWV”
K2
Lx - ASCII Message Terminator
Setting
Configuration code
CR LF
L1
LF
L2
