22
Pre-Start Checks
Fuel
The Ginetta G55 on average uses approx. 1.2L per minute (although this should be checked throughout testing, see
page 37 for more information on fuel usage). To ensure the first session is completed without any fuel issues put 45L
into the car.
Ensure fuel is vented correctly when filling car, and always fill the same side on each fill to avoid airlocks.
Only use fuel with an octane rating of 98 or higher and under less than 2% oxygenated.
Spanner Check
The car needs to be spanner checked before leaving the workshop, and daily whilst at track. Using the supplied
checklists on pages 32, 33, and 35, as part of a routine visual check will ensure nothing is over looked.
Fluids
Engine oil: 8L (from a dry system) Carlube 10W60 Fully Synthetic Motorsport Racing Oil
Gearbox oil: 2.25L (from a dry system) 75w90
1.25L for the gearbox, 1L for the cooler and lines
Diff oil: Approx. 2.1L / up to fill hole- 80W90
Brake and Clutch fluid: RBF 600
Power steering fluid: Fuchs ATF 6000 SL
Clutch and Brake
Brake
Clutch
Figure 5.1
Figure 5.1 shows the two brake fluid
reservoirs as well as the clutch fluid
reservoir.
Each reservoir has a line to indicate
the level of fluid that should be
inside, ensure all three are filled to
the correct level.
