32
Workshop Preparation Checklist
Date:
Chassis:
Mechanic:
Job list
Yes
No
Quantity
Comments
Set down
Check for any bodywork damage
Check windscreen for damage
Check wheels for play before removal
Straight edge wishbones, any bent?
Check brake pads and discs for wear
Remove sills, check for any rubber / blow out
All exhaust springs still attached?
Check exhaust side brackets for cracks
Check cats
Check backbox hangers for snapping
Blow out radiators, check for leaks
Full spanner check
Roll bar adjuster nuts tight?
Manifold bolts tight?
Toe link lock nuts tight?
Check prop bolts both ends
Check damper bushes for play
Check brake line routing
Drain catch tank, replace drain plug
Drive shaft nuts
Drive shaft play?
Check hub nut torque (180 ftlb)
Remove gearbox and check clutch plates for wear
Remove floor trays, check for leaks
Any damage to underside?
Full clean underneath
Refit floor trays with new bolts
Full spanner check pedal box, pedal pads too
Check seat rail and mount bolts
Check wiring and piping in engine bay for chafing
Bleed brakes
Clean bleed nipples
Does clutch need a bleed?
Check water and power steering fluid
Check engine oil, when was filter last changed?
Does gearbox oil need checking?
Drain paddleshift air tank
Check paddles on wheel for swarf
Drain fuel, how much came out?
Refuel, how much? 10L for setup if unsure
Set dampers, what are bump and rebound set to?
Full clean outside, clean glass too
