Glidermatic™
Commercial Door Operator
User Manual
2
Drive Unit
This manual refers to settings and connections to be performed on the DRIVE UNIT and CONTROL UNIT,
not the installation of the door.
Exploded Parts Diagram
1. Drive unit 1/2 HP DC motor(s)
2. Gear Heads
3. Planetary gear housing
4. Drum wheel
5. Open and close limit switches
6. Cam gears
7. Emergency chain hoist
8. Plunger
9. Cut-out switch
1
1
2
7
9
8
5
6
3
2
4
