Page 75
SmartOne C User Manual Confidential & Proprietary Information
9100-0410-01 R2.4
APPENDIX K - EXTERNAL INPUT CABLES
INSTRUCTIONS AND WIRING DIAGRAM FOR SMARTONE C EXTERNAL INPUT CABLES
5v Cable (PN# 2030-0305-01)
&
22v Cable (PN# 2030-0307-01)
.
NOTES
1. When using the 5V external input cable (PN# 2030-0305-01), the supply voltage applied to the Line Power +
wire must be 5.0 +/- 0.25 VDC. Applying a different voltage will either damage the SmartOne C or cause it to
function improperly/shutdown.
2. When using the 8-22 VDC external input cable (PN# 2030-0307-01), the supply voltage applied to the Line
Power + wire must be between 8.0 VDC and 22 VDC. If less than 8 VDC is applied, the regulator will not
function properly. If more than 22 VDC is applied, there is a strong possibility that the regulator inside the cable
will be damaged.
3. If directly connecting your source to Line Power +, the voltage must be 5.0 VDC.
4. This cable is designed to only work with 3.3 VDC logic. Do not use with 5 VDC logic devices.
5. Be certain that unused wires do not short to each other.
6. All ground wires are common; therefore, any ground can be used with any function.
7. Battery voltage is regulated differently internal to the SmartOne unit than Line Power voltage.
COLOR FUNCTION
BROWN Setup (Handshake from Serial Device)
RED RX
ORANGE TX (to Serial Device RX)
LIGHT BLUE Dry Contact 2
WHITE Dry Contact 1
YELLOW Soft Power Down (Normally Open)
GREEN Ground
BLUE Ground
VIOLET Line Power +
