SECTION VIIC SERVICE PROGRAMMING SYSTEM
2005 Tech 2 User’s Guide VII - 56
• Under “Select ECU Location,” select Off-Board Programming Adapter.
• Select Next.
4. Follow the directions on the Preparing for Communication screen (Figure VIIC-35) for connecting the
control module, OBPA, and Tech 2. Be sure to use the correct connector for the control module.
5. With the connection screen still up on the PC, go to the Tech 2 and select the Service Programming
“Request Information” function. Follow the Tech 2 instructions to obtain module data and security
information.
6. After the Tech 2 has received data from the module, exit the “Request Info” mode and disconnect the
Tech 2 from the OBPA. Power down the Tech 2.
7. Connect the Tech 2 to the PC (Figure VIIB-4). Power up the Tech 2.
8. After the Tech 2 start-up screen appears, select Next at the PC.
9. At the PC, enter the VIN of the vehicle that will be receiving the control module. Select Next.
10. The PC will display the message “Please wait! Attaching to database.”
IMPORTANT
When selecting the vehicle configuration index (VCI) programming type, a valid VCI number for the
vehicle must be entered. This number may be obtained from the Techline Customer Support Center.
OBPA Remote SPS Procedure continued on next page...
Figure VIIC-35
Preparing for Communication screen (OBPA)
