SECTION VI TROUBLESHOOTING
2005 Tech 2 User’s Guide VI - 6
Figure VI-9
Diagnostic chart for Tech 2 Main Printed Circuit Board (PCB)
Figure VI-10
Diagnostic chart for Tech 2 Vehicle Communications Interface (VCI) module
Figure VI-11
Automated Main PCB test selected on Tech 2 Self Test main menu
Figure VI-7
Main Details selection
Figure VI-8
VCI Details selection
F1: Automated Main PCB Test
This test works the same as the Automated Main PCB and VCI test, except the VCI portion of the test is
not included (Figure VI-11).
F2: Automated VCI Test
This test works the same as the Automated Main PCB and VCI test, except the PCB portion of the test is
not included (Figure VI-12).
Figure VI-12
Automated VCI test selected on Tech 2 Self Test main menu
