VCI MODULE DIAGNOSTIC CHART
Test Results Solution
MUX
(Multiplexer)
MUX A: S5 & S14
pass/fail
MUX B: S1 & S3
pass/fail
If MUX A or B fails, cycle Tech 2 power and retest.
If problem persists, contact Customer Support.
VCI adapter ID
(performed only during
selectable VCI test)
Recognized adapter
Cannot identify adapter
If adapter fails, use a different adapter to make sure
that the VCI correctly identifies the adapters.
Cycle Tech 2 power and retest failed adapter. If adapter
fails second test, contact Customer Support.
VCI ADC
(Analog to digital converter)
Channel A - pass/fail
Channel B - pass/fail
If a failure occurs, cycle Tech 2 and retest.
If problem persists, contact Customer Support.
If channel A or channel B fail, cycle Tech 2 and retest.
If problem persists, contact Customer Support.
Cross point Pull up - pass/fail
TPU5, TPU1, and TPU0 - pass/fail (results
from selectable VCI test)
SIPO
(Serial In Parallel Out)
Pass/fail for each area tested If a failure occurs, cycle Tech 2 and retest.
If problem persists, contact Customer Support.
DLC
(Data Link Connector)
DLC1 - DLC2
pass/fail count
DLC2 - DLC1
pass/fail count
If a failure occurs, cycle Tech 2 and retest.
If problem persists, contact Customer Support.
CCD
(Chrysler Collision Detection)
CCD - pass/fail
CCD - loopback not connected
Connect loopback and retest if loopback not connected.
If test fails, disregard results. Test is not for GM vehicles
(other than Saab) at this time.
Continued on next page...
