SECTION III GETTING STARTED
2005 Tech 2 User’s Guide III - 10
How to Connect the Tech 2 to a Computer Terminal
Follow the steps below and refer to Figure III-26, which illustrates the typical Tech 2 connection to a
computer terminal.
1. Plug the serial port adapter (P/N TA00040) into the serial port marked “A” or “1” on the back of the
computer terminal or to the USB port using the USB serial adapter.
2. Plug the Tech 2’s RS-232 cable into the serial port / USB port adapter and connect the appropriate
power supply.
3. After power is supplied to the Tech 2 and the [PWR] button is pressed, the Tech 2 start-up display
should appear on the Tech 2 screen (Figure III-27).
Figure III-26
Typical Tech 2 connection to a computer terminal (rear view)
Figure III-27
Tech 2 displaying the Tech 2 start-up screen
