SECTION III GETTING STARTED
2005 Tech 2 User’s Guide III - 6
Figure III-16
Location of soft keys
Soft Keys
Four soft keys are located directly below the Tech 2 screen (Figure III-16). The soft keys correspond
directly to the four possible selection boxes found at the bottom region of the Tech 2 screen. These
selections may change from screen to screen and are under the control of the application software. To
make a screen selection, press the corresponding soft key. In the example shown in Figure III-17, the first
soft key was pressed to select [Display Time].
Figure III-17
Soft key selection for display time
Selection Keys
The Tech 2 selection keys are four directional arrow keys (Figure III-18). Press the arrow keys to move the
highlighted area to a selection on the screen (Figure III-19) or to scroll the screens if more than one. Once
the desired selection is highlighted, press [ENTER] to activate the selection.
Figure III-18
Location of selection keys
Figure III-19
Positioning the highlighted area to make a selection
