SECTION V ADAPTERS
2005 Tech 2 User’s Guide V - 1
Adapters
A number of adapters are available for the Tech 2 which allow connection to many different vehicles
(Figure V-1 and Figure V-2). Specific adapters are included in the Tech 2 base kit depending upon Tech 2
configuration—NAO, International, Saab, Opel, Vauxhall, etc. Adapters not included in the base kit may be
purchased separately from your tool distributor.
DLC Cable
The DLC cable (P/N 3000095) has a 26-pin connector with thumb screws at one end that connects to the
Tech 2’s VCI cable connector. At the other end is a 19-pin connector that connects to a variety of adapters
(Figure V-1 and Figure V-2).
Figure V-1
DLC cable adapter connections
Figure V-2
Table showing various adapters and their part numbers
RS-232 Cable
The RS-232 cable (P/N 3000110) has an 8-pin RJ45 plug connector at each end (Figure V-3). This cable
attaches to the Tech 2 RS-232 port and is used to communicate with the Techline terminal.
Figure V-3
RS-232 cable connections
