SECTION VI TROUBLESHOOTING
2005 Tech 2 User’s Guide VI - 7
F3: Selectable Main PCB Test
Choose F3: Selectable Main PCB (Figure VI-13) after a fail message has been displayed during the
Automated Main PCB and VCI or Automated Main PCB tests. When you choose F3: Selectable Main
PCB, a screen like the one shown in Figure VI-14 is displayed. You may then select individual tests for
failed components. For specific information on failed components, refer to the Main Printed Circuit Board
(PCB) Diagnostic Chart (Figure VI-9).
Figure VI-13
Selectable Main PCB test selected on Tech 2 Self Test main menu
Figure VI-14
Selectable Main PCB Self Test screen
