SECTION VI TROUBLESHOOTING
2005 Tech 2 User’s Guide VI - 10
Figure VI-23
Cigarette lighter power cable three-amp fuse replacement
Cigarette Lighter Power Cable 3-Amp Fuse Replacement
A three-amp removable fuse is located in the cigarette lighter power cable (P/N 3000096) connector
(Figure VI-23). When required, check or replace the fuse by performing the following steps:
1. Ensure cigarette lighter power cable is not connected to vehicle or Tech 2.
2. Unscrew fuse retainer cap and remove three-amp fuse.
3. Inspect fuse for damage and replace with identical three-amp fuse if required.
4. Verify by connecting cigarette lighter power cable to Tech 2 and vehicle.
