SECTION VI TROUBLESHOOTING
2005 Tech 2 User’s Guide VI - 11
Figure VI-24
Battery power cable three-amp fuse replacement
Battery Power Cable 3-Amp Fuse Replacement
Two three-amp fuses are located in the battery power cable (P/N 3000097) three-amp fuse box
(Figure VI-24). When required, check or replace the fuse(s) by performing the following steps:
1. Ensure battery power cable is not connected to vehicle battery or Tech 2.
2. Use a standard fuse puller to remove the fuse(s) from the fuse box.
3. Inspect fuse(s) for damage and replace with identical 3-amp fuse(s) if required.
4. Verify by connecting battery power cable to Tech 2 and vehicle battery.
CAUTION:
To help avoid personal injury by electric shock, make sure the battery power cable is not
connected to the vehicle’s battery before removing the fuse(s).
