SECTION IV POWER SUPPLIES
2005 Tech 2 User’s Guide IV - 3
NAO Power Supply
North American electrical supply is normally 110 volts. The Tech 2 base kit includes an external AC to DC
power supply with 110 V AC/60 Hz input (Figure IV-2). Output is 12 volts at 1.5 amps.
Universal Power Supply
Wherever 220 current is required, use the 110/220 V AC/50 Hz external AC to DC power supply
(Figure IV-2). A specific power cord is provided to permit connection to your area’s power cord receptacle.
Figure IV-2
Tech 2 power supplies (NAO and Universal)
CAUTION
To avoid personal injury due to electric shock, use grounded outlet only. The NAO power supply
is for North American use only. The Universal power supply is for use outside North America.
These devices are intended for indoor use only.
Figure IV-3
Table showing various types of power cord plugs for the Tech 2
Power Cord Plugs
Various types of power cord plugs are available for the Tech 2, depending your geographic location
(Figure IV-3).
