SECTION I INTRODUCTION
2005 Tech 2 User’s Guide I - 5
Tech 2 Overview
The Tech 2 is a hand-held computer designed to aid in diagnosis and repair of automotive systems with
electronic controls and interfaces.
Figure I-1
External features of the Tech 2 (front view)
Hardware
The Tech 2 has been designed as a rugged, shop-ready tool by having:
• A sturdy case
• A sealed keypad
• Heavy-duty cables and connectors
You can expect years of trouble-free service if you take reasonable care of the Tech 2 and follow the
maintenance procedures outlined in Section II.
Figure I-2
Table listing Tech 2 base kit part numbers and descriptions (see Section III for illustrations)
Figure I-3
Table listing part numbers for Tech 2 adapters and accessories (see Sections V and Section VII)
Video clip 1 (38 seconds)
90-degree adapter (J42598-20) installation demo*
*After viewing, click the X in the upper right-hand corner of the video window to close.
