SECTION III GETTING STARTED
2005 Tech 2 User’s Guide III - 8
Tech 2 Connection to Vehicle
The Tech 2 receives power through the DLC cable connection to vehicles equipped with On-Board
Diagnostics (OBD II) (Figure III-23). In the case of vehicles not equipped with OBD II, an external power
source such as a vehicle cigarette lighter must be used (Figure III-24).
Figure III-24
Attaching the Tech 2 to non-OBD II equipped vehicles
Figure III-23
Attaching the Tech 2 to OBD II equipped vehicles
