SECTION VI TROUBLESHOOTING
2005 Tech 2 User’s Guide VI - 14
Figure VI-30
CANdi Diagnostics menu: “POST Results” or “Self Test”
When you select “POST Results” from the CANdi Diagnostics menu (Figure VI-30), the screen shown in
Figure VI-31 appears. You can use the information to determine if the CANdi module had any problems
during its start-up sequence. Software and hardware revision numbers are identified and displayed.
Figure VI-31
CANdi POST Results screen
Selecting “Self Test” from the CANdi Diagnostics menu (Figure VI-30) initiates a complete test of the
CANdi module. When testing is complete, all results are displayed on the screen shown in Figure VI-32.
Figure VI-32
CANdi Self Test Results screen
CANdi Module Diagnostics
Select “CANdi Diagnostics” from the Tech 2’s Tools Options menu (Figure VI-29), and the screen shown in
Figure VI-30 appears. If the CANdi module is not connected, the screen shown in Figure VI-27 appears.
Figure VI-29
CANdi Diagnostics selected on Tool Options menu
