SECTION VIIB TIS SOFTWARE
2005 Tech 2 User’s Guide VII - 26
Figure VIIB-18
DTC display mode (“2 of 4”)
Figure VIIB-17
“View DTC Information” icon selected on the Snapshot toolbar
Displaying Diagnostic Trouble Codes
The View Diagnostic Trouble Code Information mode displays all relevant trouble code information for
each individual frame. Note that when replaying a snapshot, every frame of the snapshot may not have a
stored DTC.
To use the DTC display feature:
1. Select the View DTC Information icon on the Snapshot toolbar. A box will appear near the top of the
screen listing DTC information (see Figure VIIB-17). The following information is provided:
• The first line indicates how many codes are in the frame—e.g. “1 of 2,” “2 of 2,” etc. This is not the
total number of DTCs stored in the entire snapshot, just in the individual frame being displayed.
• Below the first line is the number and name of the DTC.
• Diagnostic test status tells whether the test ran and whether it passed or failed.
• DTC status lists the DTC information. This is the status of the tests that were run and the related DTC
messages that can be viewed by the technician. This information is based only on the DTC
information listed, since some DTC information will not be available on all applications.
2. If more than one DTC is set for a frame, scroll bars will appear at the right side of the DTC window. To
view other DTCs (Figure VIIB-18), click-and-drag the scroll box or use the scroll arrows.
Displaying DTCs continued on next page...
