SECTION VIIC SERVICE PROGRAMMING SYSTEM
2005 Tech 2 User’s Guide VII - 41
STEP 2: Transfer Data from the PC to the Tech 2
2.1 Connect the Tech 2 to the terminal, as shown in Figure VIIB-4.
2.2 At the terminal, launch TIS.
2.3 From the TIS main screen (Figure VIIB-2), select the Service Programming System icon.
2.4 At the Select Diagnostic Tool and Programming Process screen (Figure VIIC-2), make the
appropriate selection for your procedure:
• Under “Select Diagnostic Tool,” select Tech 2.
(You would select Information Only/PROM data to get calibrations for a particular vehicle without
using the Tech 2, or to get PROM data for vehicles that cannot be programmed. You would select
Pass-Thru to perform SPS without disconnection from the vehicle or the terminal.)
• Under “Select Programming Process,” select Reprogram ECU or Replace and Program ECU,
depending on whether you are reprogramming an existing module or replacing a module.
• Under “Select ECU Location,” select Vehicle or Off Board Programming Adapter (OBPA),
depending on whether you are performing on-vehicle or off-board programming.
2.5 After making selections, select Next.
2.6 Confirm connections and select Next on the Preparing for Communication screen (Figure VIIC-3).
Figure VIIC-2
Select Diagnostic Tool and Programming
Figure VIIC-3
Preparing for Communication screen
Performing Remote SPS, Step 2, continued on next page...
IMPORTANT
If you answered NO to the VIN in step 1.7, a box may appear stating “The ECU could be a service
ECU.” Click OK.
