SECTION VIIC SERVICE PROGRAMMING SYSTEM
2005 Tech 2 User’s Guide VII - 44
2.11 After making the necessary selections, a Summary screen will appear (Figure VIIC-9) allowing you
to confirm your selection. Select Next to continue.
Note: If calibrations are the same, the NAODRUI Control box appears (Figure VIIC-10) stating that
the calibrations selected are already the current calibrations in the control module. Click OK
and Back out or click Cancel on the Summary screen.
2.12 The application will automatically initiate the download of the new calibration file to the Tech 2, and a
Transfer Data screen (Figure VIIC-11) will track the progress of the download.
2.13 After the download is complete, a Program Controller screen (Figure VIIC-12) will appear with
instructions for connecting the Tech 2 to the vehicle to complete the programming process.
Close the application to return to the TIS Application Selection screen, then power down and
disconnect the Tech 2 from the PC.
Controller Specific Instructions.
If “Crankshaft Position Variation Relearn Procedure” appears under “Controller Specific
Instructions,” you must perform this procedure after reprogramming the PCM/VCM.
Refer to Service Manual DTC P1336 or P315CKP (System Variation Not Learned) for this
procedure.
Figure VIIC-10
NAODRUI Control box
Figure VIIC-11
SPS Transfer Data screen
Figure VIIC-12
SPS Program Controller screen
Figure VIIC-9
SPS Summary screen to confirm calibration
