SECTION VIIC SERVICE PROGRAMMING SYSTEM
2005 Tech 2 User’s Guide VII - 47
Tech 2 SPS User Interface Screens and Functionality
Overview
This section is a representation of the Tech 2 Service Programming System (SPS) user interface screen
application. User interface screens that could be encountered during the execution of Tech 2 remote SPS
are shown. The Tech 2 screen information is organized into two sections: Requesting Information and
Programming. Follow the steps to perform remote SPS using the Tech 2 scan tool and TIS software.
Requesting Information
1. At the Tech 2 title screen, select Enter. To execute the SPS application, press F1 on the Tech 2 keypad
or highlight Service Programming System on the Main Menu screen (Figure VIIC-13), then press
Enter.
2. At the Request Information screen (Figure VIIC-14), press F0 or Enter.
Note: ECU to be programmed must be installed before requesting information.
3. At the Salesmake(s) screen (Figure VIIC-15), highlight one of the salesmakes, then select Enter.
Note: Information entered incorrectly may result in programming errors.
Figure VIIC-14
Request Info screen
Figure VIIC-15
Salesmake(s) screen
Figure VIIC-13
Tech 2 Main Menu screen with SPS selected
Tech 2 SPS Screens and Functionality continued on next page...
