TX667 Instruction Manual
17
REPLACING THE BATTERY PACK
Note: Removing the belt clip rst will provide easier access to the battery cover.
1. Ensure the radio is switched o.
2. Hold the radio face down in your hand with the battery cover
facing upwards.
3. Slide the battery cover downwards with your them, then lift the
cover clear to remove it.
4. Unplug the connector at the top of the battery compartment and
remove the battery.
5. Place the new battery in the battery compartment.
6. Plug the connector into the socket ensuring the red (positive) wire
is on the right (the connector should only t one way).
7. Reinstall the battery cover ensuring the wires do not become
jammed in the cover.
