8. Installation
1.
Mount the go-e Charger approx. 1.00 to 1.45
meters above the ground, depending on your
personal feeling of well-being.
Place the wall bracket in the desired mounting
position. Use a spirit level to align it straight.
Mark the four drill holes with a pencil by using
the wall bracket as a template.
Required tools
bPencil Spirit level Measuring tape Drilling machine
Screwdriver Hammer Cutter knife Side cutter
Dowel 8 x 40 mm Screws for wall bracket 4.5 x 50 mm
Screw for U-piece 4 x 50 mm
U-piece (optional anti-theft device) Wall bracket
Enclosed mounting material
e
5x 4x 1x
4X
1 M - 1.45 M
a
a
c
c
d
d
e
e
f
f
g
g
h
h
