[page 22] | gpelectric.com
58. Starter Voltage Display
Must be ON to display the auxiliary voltage in the monitoring menu.
59. Temperature Display
Must be ON to display the temperature in the monitoring menu.
60. Mid Voltage Display
Must be ON to display the mid-point voltage in the monitoring menu.
Default Range
OFF OFF/ON
5.2.5 MISCELLANEOUS
61. Software Version (Read Only)
The software version of the GP-BMK-50.
62. Restore Defaults
Resets all settings to factory default by pressing SELECT. When in normal operating mode, factory settings can
be restored by pressing SETUP and SELECT simultaneously for 3 seconds (only if setting 64, Lock setup, is o).
63. Clear History
Clears all history data by pressing SELECT.
64. Lock Set-Up
When on, all settings (except this one) are locked and cannot be altered.
Default Range
OFF OFF/ON
65. Shunt Current
When using a shunt other than the one supplied with the BMK, set to the rated current of the shunt.
Default Range Step size
500A 1-9999A 1A
66. Shunt Voltage
When using a shunt other than the one supplied with the BMK, set to the rated voltage of the shunt.
Default Range Step size
50mV 1mV-75mV 1mV
67. Temperature Unit
CELC - Displays the temperature in °C.
FAHR - Displays the temperature in °F.
Default Range
CELC CELC/FAHR
FULL SET-UP DETAILS
