5.2.3 ALARM BUZZER SETTINGS
Remark: thresholds are disabled when set at 0.
32. Alarm Buzzer
When set, the buzzer will sound an alarm. After a button is pressed the buzzer will stop sounding. When disabled
the buzzer will not sound an alarm.
Default Range
ON ON/OFF
33. Low SOC Alarm
When the state-of-charge falls below this value for more than 10 seconds the low SOC alarm is turned on. This is
a visual and audible alarm. It does not energize the relay.
34. Clear Low SOC Alarm
When the state-of-charge rises above this value, the alarm is turned o. This value needs to be greater than or
equal to the previous parameter.
Default Range Step Size
0% 0-99% 1%
35. Low Voltage Alarm
When the battery voltage falls below this value for more than 10 seconds the low voltage alarm is turned on. This
is a visual and audible alarm. It does not energize the relay.
36. Clear Low Voltage Alarm
When the battery voltage rises above this value, the alarm is turned o. This value needs to be greater than or equal
to the previous parameter.
37. Low Voltage Alarm
When the battery voltage rises above this value for more than 10 seconds the, low voltage alarm is turned on. This
is a visual and audible alarm. It does not energize the relay.
38. Clear High Voltage Alarm
When the battery voltage falls below this value, the alarm is turned o. This value needs to be less than or equal to
the previous parameter.
GP-BMK-50
Default Range Step Size
0V 0-95V 0.1V
39. Low Starter Voltage Alarm
When the auxiliary (e.g. starter battery) voltage falls below this value for more than 10 seconds the alarm will be
activated. This is a visual and audible alarm. It does not energize the relay.
