25. Clear High Starter Voltage Relay
When the auxiliary voltage falls below this value, the relay will open (after a delay, depending on setting 14 and/or
15). This value needs to be less than or equal to the previous parameter.
Default Range Step Size
0V 0-95V 0.1V
26. High Temperature Relay
When the battery temperature rises above this value for more than 10 seconds, the relay will be activated.
27. Clear High Temperature Relay
When the temperature falls below this value, the relay will open (after a delay, depending on setting 14 and/or 15).
This value needs to be less than or equal to the previous parameter.
28. Low Temperature Relay
When the temperature falls below this value for more than 10 seconds, the relay will be activated.
29. Clear Low Temperature Relay
When the temperature rises above this value, the relay will open (after a delay, depending on setting 14 and/or 15).
This value needs to be greater than or equal to the previous parameter. See setting 67 for choosing between °C
and °F.
Default Range Step Size
0°C -99 - 99°C 1°C
0°F -146 - 210°F 1°F
30. Mid Voltage Relay
When the mid-point voltage deviation rises above this value for more than 10 seconds, the relay will be activated.
See section 5.2 for more information about the mid-point voltage.
31. Clear Mid Temperature Relay
When the mid-point voltage deviation falls below this value, the relay will open (after a delay, depending on setting
14 and/or 15). This value needs to be less than or equal to the previous parameter.
Default Range Step Size
0% 0-99% 0.1%
FULL SET-UP DETAILS
