2.5 Notes on the Pulse/Digital Inputs
The BlueSense Module has 4 galvanically isolated digital inputs.
Pulse Inputs 1 and 2:
The assignment of the pulse inputs 1 and 2 is set at connector X7 and X8.
The pulse inputs 1 and 2 are provided for the connection of PNP or NPN encoders:
• The selection between PNP and NPN is set at the associated jumper slots.
• Assignment see 2.2 Connection Diagram 1 Control Parameter
or 2.3 Connection Diagram 2 Control Parameter
The two pulse inputs 1 and 2 can also be used as static inputs:
• Selection PNP: Signal at connection of 24 V and PNP
• Selection NPN: Signal at connection of GND and NPN
• Assignment see 2.2 Connection Diagram 1 Control Parameter
or 2.3 Connection Diagram 2 Control Parameter
Digital Inputs 3 and 4:
The digital inputs 3 and 4 are static inputs.
The assignment of the digital inputs 3 and 4 is set at connector X6.
• Digital input 3: Signal at connection of the two lower clamp sockets
• Digital input 4: signal at connecting the two upper clamping sockets
• Assignment see 2.2 Connection Diagram 1 Control Parameter
or 2.3 Connection Diagram 2 Control Parameter
At static use all 4 digital inputs are closers (NO = normally open).
2.6 Hazard Note
Danger: Improper handling of electrical devices endangers man and property.
Let carry out the commissioning of the BlueSense Module only by skilful, trained personnel using
appropriate tools. Incorrect installation could cause serious faults and errors that may damage
the device.
