Godex DT2 User Manual

1
DT2 / DT4 series User Manual
1. Barcode printer
1-1. Box content
Please check that all of the following items are included with your printer:
 Barcode printer
 Power cord
 AC adapter
 USB cable
 Label stock
 Quick reference guide
 CD (with QLabel label software / user manual)
DT2 series DT4 series
1-2. Specifications
Model
DT2
DT4
Print Method
Direct Thermal
Resolution
203 dpi (8 dot/mm)
Print Speed
4 IPS (102 mm/s)
4 IPS (102 mm/s)
Print Width
2.12” (54 mm)
4.25” (108 mm)
Print Length
Min. 0.16” (4 mm)** ; Max. 68” (1727 mm)
Processor
32 Bit RISC CPU
Memory
4MB Flash (2MB for user storage) ;
16MB SDRAM
8MB Flash (4MB for user storage) ;
16MB SDRAM
Sensor Type
Adjustable reflective sensor. Fixed transmissive sensor, central aligned
Media
Types: Continuous form, gap labels, black mark sensing, and punched
hole; label length set by auto sensing or programming
Width: 0.6” (15 mm) Min. - 2.36” (60
mm) Max.
Thickness: 0.003” (0.06 mm) Min. -
0.008” (0.20 mm) Max.
Label roll diameter: Max. 5” (127
mm)
Core diameter: 1”, 1.5” (25.4 mm,
38.1 mm)
Width: 1” (25.4 mm) Min. - 4.64” (118
mm) Max.
Thickness: 0.003” (0.06 mm) Min. -
0.008” (0.20 mm) Max.
Label roll diameter: Max. 5” (127
mm)
Core diameter: 1”, 1.5” (25.4 mm,
38.1 mm)
Printer Language
EZPL, GEPL, GZPL, auto switch
Software
Label design software: GoLabel (for EZPL only)
Driver: Windows 2000, XP, Vista, 7, 8 , Windows Server 2003 & 2008
DLL: Windows 2000, XP and Vista

Godex DT2 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi
Print Width	54 mm
Interface	USB
Type	Desktop
Supported Barcodes	Code 39, Code 128, UPC, EAN, QR Code, Data Matrix
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	20% to 85% RH (non-condensing)
