Godex DT2 User Manual

3
DT2 / DT4 series User Manual
Model
DT2x
Print Method
Direct Thermal
Resolution
203 dpi (8 dot/mm)
Print Speed
7 IPS (177 mm/s)
Print Width
2.12” (54 mm)
Print Length
Min. 0.16” (4 mm)** ; Max. 68” (1727 mm)
Processor
32 Bit RISC CPU
Memory
4MB Flash (2MB for user storage) ; 16MB SDRAM
Sensor Type
Adjustable reflective sensor. Fixed transmissive sensor, central aligned
Media
Continuous form, black mark sensing, and punched hole; label length
set by auto sensing or programming
Width: 0.6” (15 mm) Min. - 2.36” (60 mm) Max.
Thickness: 0.003” (0.06 mm) Min. - 0.008” (0.20 mm) Max.
Label roll diameter: Max. 5” (127 mm)
Core diameter: 1”, 1.5” (25.4 mm, 38.1 mm)
Printer Language
EZPL, GEPL, GZPL, auto switch
Software
Label design software: GoLabel (for EZPL only)
Driver: Windows 2000, XP, Vista, 7, 8 , Windows Server 2003 & 2008
DLL: Windows 2000, XP and Vista
Resident Fonts
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°
rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable
Download Fonts
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°
rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in
horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable

Godex DT2 Specifications

General

Print Method	Direct Thermal
Resolution	203 dpi
Print Width	54 mm
Interface	USB
Type	Desktop
Supported Barcodes	Code 39, Code 128, UPC, EAN, QR Code, Data Matrix
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	20% to 85% RH (non-condensing)
