C. Technical Specification
EZ-2 EZ-4
Print method Direct thermal
Max. paper width 2.36" (60 mm) 4.64" (118 mm)
Max. printing width 2.20" (56 mm) 4.09" (104 mm)
Max. print speed 2" per second (50.8 mm/Sec)
Dot density 203 dots per inch (8 dots per mm)
Power requirement AC 13.5V ~ 16.0V; 3A ~ 5A.
DC 18.0V ~ 24.0V; 3A ~ 5A
AC 13.5V ~ 16.0V; 4A ~ 5A.
DC 18.0V ~ 24.0V; 4A ~ 5A
Sensor type Label gap-sizing detector.
Print head life 50K meters printing distance when apply on Thermal Labels
Dimension 144 W x 215 H x 127 D mm ---With
internal label roll
144 W x 215 H x 320 D mm ---With
external label roll
198 W x 215 H x 127 D mm ---With
internal label roll
198 W x 215 H x 320 D mm ---With
external label roll
Working Environment
Operating Temperature: 40
o
F to 104
o
F (5
o
C to 40
o
C)
Storage Temperature: -40
o
to 140
o
F (-40
o
C to 60
o
C)
Humidity: 10% to 90% non condensing, free air
Specifications are subject to change without notice.
D. Communication Ports Specification
Parallel Port
Handshake : DSTB to printer and BUSY to host.
Interface cable : DB25 Male (IBM-PC) 36 position parallel printer cable.
Pin out :
PIN NO. FUNCTION TRANSMITTER
1 Strobe host
2-9 Data 0-7 host
10 N/C printer
11 Busy printer
12 Paper empty printer
13 Select printer
14-16 N/C
17 Chassis Ground
18 N/C
19-30 Signal Ground
31 N/C host
32 Fault printer
33 Signal ground
34-36 N/C
Serial Port
Serial port is set at the factory with 9600 baud-rate, no parity, 8 data bits, and 1 stop bit and uses XON/XOFF
protocol as well as RTS/CTS.
The connector is RS-232 DB9 female. The pin assignments are listed below.
PIN NO.
1 2 3 4 5 6 7 8 9
NAME
+5 V TXD RXD DSR GND DTR N/C DTR N/C
