Godex RT700 User Manual

21
3 Printer Setting and Control
3.1 Operation Panel
021
FEED Button
When you press the FEED button, the printer moves the label to the defined stop position.
If you are using continuous labels, pressing the FEED button will move label stock until you release the button again.
If you are using individual labels, pressing the FEED button will move only one label.
If the label does not stop at the correct position, you need to run the auto-detection function on the label stock, please see Section 3.2 Label
Calibration and Self Test.
LED Indicators
OPERATION PANEL
RT700
FEED BUTTON
POWER BUTTON
STATUS LED
POWER LED
Operation Panel Introduction
POWER Button
Press the POWER button and the LED indicator lights up green. The printer is on “ Ready to print “ status now.
When printer is turned on, keep pressing the POWER button until the LED indicator lights off will turn the printer off.
LED Indicator Status Description
Green Standby The printer is ready for operation.
Red Error
The printer has detected an error.
See Section 3.3 Error Alerts.

Godex RT700 Specifications

General

Color	-
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	1727 mm
Maximum printing width	108 mm
Display	LED
Product color	Black
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Windows code pages supported	1250, 1251, 1252, 1253, 1254, 1255, 1257
Core diameter	25.4 mm
Media thickness	0.06 - 0.2 mm
Maximum label width	110 mm
Maximum label length	300 m
Maximum roll diameter	68 mm
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 85 %

Weight and Dimensions

Depth	280 mm
Width	210 mm
Height	186 mm
Weight	2700 g
