Godex RT700 User Manual

2
Front View

1 Barcode Printer
1.2 Getting to Know Your Printer
002
Device Overview
Rear View

ETHERNET PORT
SERIAL PORT
FAN-FOLD LABEL INSERT
Feed slot for continuous labels
POWER JACK
USB PORT
CALIBRATION BUTTON
COVER RELEASE CATCHES
Pull catches for opening the printer cover
LED INDICATOR
OPERATION PANEL
FEED BUTTON
POWER BUTTON
FRONT COVER
PRINTER COVER

Godex RT700 Specifications

General

Color	-
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	1727 mm
Maximum printing width	108 mm
Display	LED
Product color	Black
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Internal memory	16 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Windows code pages supported	1250, 1251, 1252, 1253, 1254, 1255, 1257
Core diameter	25.4 mm
Media thickness	0.06 - 0.2 mm
Maximum label width	110 mm
Maximum label length	300 m
Maximum roll diameter	68 mm
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 85 %

Weight and Dimensions

Depth	280 mm
Width	210 mm
Height	186 mm
Weight	2700 g
