GOEBEL GO-RN2 - 1.1 Capacity and Technical Parameters; 1.2 Configuration and Accessories

2 | Deutsch5 | English
1.1 Capacity / Technical Parameters
260
21.5 21.5 21.5
GO-RN1
10.62 11.5 2.16
10.2
2.68
1.46
3.62
1.75
3.62
2.52
2.52
3.68
0.85
Model GO-RN1 GO-RN2 GO-SN1
Motor 18V Brushless motor
Noise level < 78dB
Riveting mode Conventional riveting mode / Fully automatic riveting mode
Traction force 4000 lbft 6000 lbft 4700 lbft
Stroke .25" (adjustable) .375" (adjustable) .625" (adjustable)
Net weight (incl. battery) 3.3 lbs 3.62 lbs 3.62 lbs
Capacity 6/32 ~ 5/16-18UNC 10-24 ~ 1/2-13UNC 10-24 ~ 3/8-16UNC
Material specication All materials and specications of round shank, semi
and full hexagonal blind rivet nuts.
Split blind rivet nuts -
all materials
1.2 Conguration / Accessories
(Fig. A)
11.87
3.62
2.52
4.5 4.9
0.93
0.93
1.75 1.75
GO-RN2 GO-SN1
