GOEBEL GO-RN2 - Configuration; Accessories (See Fig. A)

Deutsch | 2 English | 6
1.2 Conguration* / Accessories (see g. A)
www.goebelfasteners.com
NO Parts description Code Spec Qty. NO Parts description Code Spec Qty.
18
Battery Li-Ion 18V 2.0 Ah 2277012410 2 21 Wrench 2277012310 1
19 Battery Charger
2277012510 1 22 ABS casing 2277013310 2
20 Allen key
2270000213 1
NO Parts description Code Spec Qty. NO Parts description Code Spec Qty.
1 Anvil
2277030111 1/4-20 1 7 Anvil 2277032010 5/16-18 1
2 Counter nut
2277030210 1 11
Mandrel
2277032411 6-32 1
3 Mandrel
2277030311 1/4-20 1 12 2277032511 8-32 1
4
Anvil
2277031711 6-32 1 13 2277032611 10-24 1
5
2277031811 8-32 1 14 2277032711 5/16-18 1
6
2277031911 10-24 1 26 Rivetbolt-puller 2277032961 8-32 1
22 Rivetbolt-puller
2277032981 1/4-20 24 Rivetbolt-puller 2277032971 10-24
GO - RN1 Conguration
* General conguration
NO Parts description Code Spec Qty. NO Parts description Code Spec Qty.
1a Anvil
2277030111 1/4-20 1 13a
Mandrel
2277032611 10-24 1
2a Counter nut
2277030210 1 14a 2277032711 5/16-18 1
3a Mandrel
2277030311 1/4-20 1 15a 2277032821 3/8-16 1
6a
Anvil
2277031911 10-24 1 16 2277033020 1/2-13 1
7a
2277032010 5/16-18 1 24 Rivetbolt-puller 2277032971 10-24 1
8
2277032121 3/8-16 1 22 Rivetbolt-puller 2277032981 1/4-20 1
9
2277032320 1/2-13 1 20 Rivetbolt-puller 2277032991 5/16-18 1
GO - RN2 Conguration
NO Parts description Code Spec Qty. NO Parts description Code Spec Qty.
1a Anvil
2277030111 1/4-20 1 8 Anvil 2277032121 3/8-16 1
2a Counter nut
2277030210 1 13b
Mandrel
2277052611 10-24 1
3b Mandrel
2277050311 1/4-20 1 14b 2277052711 5/16-18 1
6a
Anvil
2277031911 10-24 1 15b 2277052811 3/8-16 1
7a
2277032010 5/16-18 1
GO - SN1 Conguration
