1.4 Tool Parts list of the GO-RN series (see Fig. B)
*Please note that the shaded parts in the list are wear parts, serial numbers 8, 9, 13 are structural parts, serial numbers a, b and c
are their own exclusive parts for tools, and the rest are general parts.
www.goebelfasteners.com
NO Standard Code Parts description Qty. NO Standard Code Parts description Qty.
6
2277031410
Spring 1 15
2277031510
Trigger 1
9
2277030710
Gearbox 1 16
2277031610
Control unit 1
10
2277031010
Tool body screw 9 31
2277031610
Battery Li-Ion 18V 2.0 Ah 1
11
2277031110
Tool Body GO-RN 1 32
2277012510
Battery Charger Set 1
12
2277031210
Back Cover 1 33
2270000213
Allen key 1
14
2277031510
Trigger spring 1 34
2277012310
Wrench 1
NO Standard Code Parts description Qty. NO Standard Code Parts description Qty.
1
2277030111
Anvil 1/4-20 1 17
2277031711
Anvil 6-32 1
2
2277030210
Counter nut 1 18
2277031811
Anvil 8-32 1
3
2277030311
Mandrel 1/4-20 1 19
2277031911
Anvil 10-24 1
4
2277030410
Schraubkappe 1 20
2277032010
Anvil 5/16-18 1
5
2277030510
Anvil pedestal assembly 1 24
2277032411
Mandrel 6-32 1
7
2277030710
Gearbox 1 25
2277032511
Mandrel 8-32 1
8
2277030810
Brushless motor 1 26
2277032611
Mandrel 10-24 1
13c
2277031310
PCB Set 1 27
2277032711
Mandrel 5/16-18 1
2277032961
Rivbolt-puller 8-32 1
2277032981
Rivbolt-puller 1/4-20 1
2277032971
Rivbolt-puller 10-24 1
GO-RN1 Parts List
NO Standard Code Parts description Qty. NO Standard Code Parts description Qty.
1a
2277030111
Anvil 1/4-20 1
20a
2277032010
Anvil 5/16-18 1
2a
2277030210
Counter Nut 1 21
2277032121
Anvil 3/8-16 1
3a
2277030311
Mandrel 1/4-20 1 22
2277032320
Anvil 1/2-13 1
4a
2277030410
Screw cap 1
26a
2277032611
Mandrel 10-24 1
5a
2277030510
Anvil pedestal assembly 1
27a
2277032711
Mandrel 5/16-18 1
7b
2277030720
Gearbox 1
28a
2277032821
Mandrel 3/8-16 1
8b
2277030820
Brushless motor 1 29
2277033020
Mandrel 1/2-13 1
13b
2277031320
PCB Set 1
2277032971
Rivbolt-puller 10-24 1
19a
2277031911
Anvil 10-24 1
2277032981
Rivbolt-puller 1/4-20 1
2277032991
Rivbolt-puller 5/16-18 1
GO-RN2 Parts List
NO Standard Code Parts description Qty. NO Standard Code Parts description Qty.
1a
2277030111
Anvil 1/4-20 1
13b
2277051310
PCB-Set 1
2a
2277030210
Counter Nut 1
19a
2277031911
Anvil 10-24 1
3b
2277050311
Mandrel 1/4-20 1
20a
2277032010
Anvil 5/16-18 1
4a
2277030410
Screw Cap 1 21
2277032121
Anvil 3/8-16 1
5a
2277030510
Anvil pedestal assembly 1
26b
2277052611
Mandrel 10-24 1
7a
2277050710
Gearbox 1
27b
2277052711
Mandrel 5/16-18 1
8a
2277030810
Brushless Motor 1
28b
2277052811
Mandrel 3/8-16 1
GO-SN1 Parts List
List of common parts: GO-RN1, GO-RN2, GO-SN1
