Golden Eagle Talon - Installation Requirements

CombustionAirSupply
A2”insidediametermetallicpipe,eitherflexibleor
rigid,maybeattachedtotheinletatthestove’srear
(refertofigure3).Arodentguard(minimum¼”wire
mesh)/windhoodmustbeusedattheterminus(refer
tofigure4).Allconnectionsmustbesecuredand
airtightbyeither
usingtheappropriatelysizedhose
clampand/orUL‐181‐APfoiltape.

Formobilehomeinstallationsonly:2”inside
diameterpipemaybeusedforthefirst5feetof
combustionairsupplyrun;from5to10feetuse2¾”
orlargerinsidediameterpipe.

SourcesofOutside
CombustionAir
1. Infireplaces
 Chimneytop.
 Ashcleanoutdoor.
2. Forfreestandinginstallations
 Aholeinfloornearstoverearterminatingonlyinaventilatedcrawlspace.
 Aholeinthewallbehindthestove.

Ifoutsideairisnotused,itisimportantthat
combustionairiseasilyavailabletotheair
inlet.Acloseableoutsideairregistercanbe
usedintightlyinsulatedhomes.

FORAMOBILEHOMEINSTALLATIONTHE
STOVEMUSTBECONNECTEDTOANOUTSIDE
SOURCEOFCOMBUSTIONAIR.

FORMOBILEHOMEINSTALLATIONSNO
COMBUSTIONAIRSUPPLYMAYEXCEED10
FEET.

ElectricalInstallation
Voltagevariationscanleadtoseriousperformanceproblems.Theelectricalsystemisdesignedfor
120VACwithnomorethan5%variation.GoldenEagleStoveCompanycannotacceptresponsibility
forpoorperformanceordamageduetoinadequatevoltage.Ifconnectedtoanoldertwo‐prong
outlet,aseparategroundwireshouldberuntoaproperground(referthistoaqualifiedtechnician).
Alwaysroutetheelectricalcordsothatitwillnotcomeintocontactwithanyhotpartofthestove.

DONOTCONNECTTHEUNITTOAGFCISOCKETORCIRCUIT.


Werecommendconnectingtoagood
qualitysurgeprotectorthatispluggedintoa
standardthree‐prong,120V,60Hzelectricaloutlet.
Figure3
Figure4
