Golden Eagle Talon - Cleaning and Blower Maintenance

Cleaning

Itisveryimportanttoproperlyandregularlycleanyourstove.Youareburningawoodproductand
thiswillresultintheformationofash,soot,andpotentiallycreosote.Theseby‐productsmustbe
regularlyandconsistentlycleanedandremovedfromthestoveinordertoensurethatyourstove
continuestooperateefficientlyandsafely.

Impropermaintenanceaccountsformostdifficultiesthatpeoplehavewiththestove.Alackof
propermaintenancemayevenresultintheunitnotfunctioningorserioussafetyconcerns.Besure
tofollowallrecommendedmaintenanceinthismanual.Ifyouarenotsureofhowtoperformanyof
theseactionsbesuretospeakwithyourdealerorcontactourtechnicalsupportdepartmentfor
additionalinstructions.

A. HeatExchangeTubes–Yourstoveisdesignedwithabuilt‐in
heatexchangetubecleaner.Thisshouldbeuseddailyto
removeaccumulatedashonthetubes,whichreducesthe
efficiencyofyourunit.Insertthehandleend(withhole)of
thecleaningtoolontothecleaningrod(refertofigure13).
Thecleanerrodislocatedinthegrillabovethestovedoor.
Movethecleanerrodbackandforthseveraltimestoclean
theheatexchangertubes.Whenfinishedbesuretoleave
tubecleanerattherearofthestove.
B. InteriorChambers–Thetwoashdoorsinthefireboxinthe
Taloncanberemovedforperiodiccleaning(refertofigure
14).Thesedoorsallowaccesstothechamberbehindthe
firebox.



Periodically,youmustvacuumashesfromthischamber.Besure
tohaveanattachmentonyourvacuumsothatyoucangetall
thewaytotheleftandrightofthesecleanouts,andalltheway
upinsideofthesedoorstothetopofstove.

INSPECTANDCLEANBEHINDTHESECLEANING
PLATESATLEASTONCEPERTONOFPELLETS
BURNED.

Insomecasesyouwillneedtoremovecreosote,which
canaccumulaterapidlyundercertainconditions.A
smallwirebrushcanbeused.Usethesmallwirebrushtoalsocleantheinsideofthe
chamberwalls,abovetheaccessdoors.


ITISIMPORTANTTOREMOVETHISCREOSOTEBECAUSEITISHIGHLYCOMBUSTIBLE.


Figure13
Figure14
Air Switch Tube
