Golden Eagle Talon - Stove Clearances and Specifications

Specifications
Width:25¾”
Height:325/8”
Depth:237/8”
Weight:275lbs.
Fluesize:3”or4”

HopperCapacity:Upto140lbs.
(Thiscanvarywidelydependingonpelletsize,
length,anddiameter)

EPAstatus:Exempt Burntime:1lb.to5.5lbs.perhour
BTUrange:8,200to48,000


Approvedinstallations:mobilehome,alcove,conventional
Clearances
TheTalonwoodpelletstovehasbeenindependentlytestedandlistedforusewiththefollowing
clearancerequirements.Allclearancesaremeasuredininchesfromthesides,rear,andface(door
opening)orstovebody.










FloorProtection
Freestandinginstallationsrequireaminimum30”wide
by32”deepfloorprotection.Thestovemustbeplaced
onacontinuous(groutedjoints)noncombustible
materialsuchasceramictile,cementboard,brick,3/8”
millboardorequivalent,orotherapprovedorlisted
materialsuitedforfloorprotection.

THEMATERIAL(S)USEDMUSTHAVE,OR

COMBINETOHAVE,AMINIMUM
INSULATIVERATINGOF‘R1’.



Ceramictile,oranytile,requiresacontinuoussheetbeneathtopreventthepossibilityof
embersfallingthroughtothecombustiblefloorifcracksorseparationshouldoccurinthe
finishedsurface,thiswouldincludefloorprotectionforBuilt‐inraisedhearths.Check
localcodesforapprovedalternatives.
Figure1
Figure2
