DESCRIPTION OF THE WALL MOUNT CONNECTION BLOCK
7
TEKNA PLUS SE MONITOR
Description of the RCTK-PLUS wall mount connection block:
a
a
b
b
f
e
d
c
8 4 2 9 8 9 8 0 1 1 8 5 1
90
50mm.
50mm.
Colocar la parte superior de la regleta a 1,60m. del suelo.
Place the top part of the monitor connector at 1,60m.
from the floor.
Distancia mínima entre los laterales de la regleta y
cualquier objeto debe ser de 5cm.
Presionar para abrir.
Press to open.
CO D E 1174208 0
RE F
RCTK-P L U S
LO T E
IMP903 0 1 2
Max.
5mm
CABLE
Max. pelado del cable.
Max. peeled cable.
Max. câble dénudé.
Max. aanstrip lengte.
Vin
Vout
Malla
Shield
MP
Malla
Shield
CETK590
A
D
INT
SA
CTO
OA1
VP
OA1
( )
*
( )
*
( )
*
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
Vin
Vout
Malla
Shield
HZ-
INT
SA
AP+
2C
VP
MP
Malla
Shield
A1
PLUS
A
D
Vin
Vout
Malla
Shield
HZ-
SA
2C
A1
VP
MP
MP
Malla
Shield
VP
a. (x6).Holes for fixing to wall
b. (x2).Monitor fixing clips
c. Vertical wiring entry.
d. Fixing clip.
e. Central wiring entry.
f. Connection terminals:
positive, negative
.
video signal input through coaxial cable.
.coaxial cable mesh
video signal output through coaxial cable.
.audio communication
.digital communication
.door bell push button input
intercom.
.auxiliary call repeater output
.auxiliary door opening push button input
.2nd camera activation output
auxiliary device activation output.
balanced video signal (through twisted pair).
+, –:
Vin :
M :esh
Vout :
A :
D :
HZ- :
INT :
SA :
:AP+
2C :
A1 :
Vp, Mp :
The +, and mesh terminals are duplicated to facilitate the cascade connection of other monitors or telephones. If the-
monitor is not positioned on the wall mount connection block, the cascade connected monitors or telephones will not
receive power.
