Commander III
2-10
is placed in the on (I) position and will stop operating
when the switch is placed in the off (O) position.
235
Auto-Float® Switch: Used to keep the optional Auto-
Float® from running when moving the machine about
the job. When the switch is in the “I” (on) position, the
starting and stopping of the Auto-Float® is controlled
by the travel of the machine. When the machine travel
is stopped, the Auto-Float® will stop. The Auto-Float®
will begin operation when the machine forward travel is
resumed. When the switch is in the "O" (off) position,
the Auto-Float® will not run when the machine is
moving. The switch must be in the “I” position during
pouring operations. The Auto-Float® will only operate
when the machine is traveling in the forward direction.
230
PTA switch: Used to raise or lower the PTA (powered
transition adjuster) in the paving mold. Move the
switch up (↑) to raise the crown of the paving mold and
move the switch down (↓) to lower. Release the switch
to stop movement.
233 & 234
Vibrator Off/Auto switch: Used to control the off
or automatic operation of the vibrator systems. The
vibrators will start and stop automatically with the
switch placed in the auto ( ) position. The vibrators
will not operate with the switch placed in the off ( )
position. See the travel variable control dial for more
information.
232
Vibrator Position Switches: Used to control the up
and down position of the vibrators. Move the switch
up (↑) to raise the vibrators and down (↓) to lower.
W158
Contact with moving auger or conveyor can cause
serious injury. Be certain that no one is near the
auger or conveyor before operation. Keep hands,
feet and loose clothing away from moving parts to
prevent severe injury. Keep all guards and shields
in place.
Auger Variable Control Dial: Used to control the
speed of the left and right augers in either forward
or reverse directions of rotation. The auger will
stop when the corresponding dial is turned to the
“off” position (all the way counterclockwise). The
auger will begin to rotate and increase speed as the
corresponding dial is turned clockwise. The auger will
decrease rotation speed as the corresponding dial is
turned counterclockwise.
Auger Direction Switches: Controls the rotation
direction of the left and right augers. Move the switch
up (↑) to rotate the corresponding auger to the left and
move the switch down (↓) to rotate the auger to the
right. Center position will stop the operation of the
auger.
Frame Extend Switches: Used to hydraulically
extend the main frame up to 6 feet (1.83 meters).
Move the switches down (↓) to extend the frame and
up (↑) to retract. Both switches should be operated
simultaneously to extend or retract the frame evenly.
098
Tamper On/Off Switch: Controls the on or off
operation of the tamper bar in a paving form. The
tamper bar will operate when the switch is placed in
the on (I) position and will not operate in the off (O)
position. The tamper bar will automatically start and
stop with paver travel in the same manner as the
vibrator systems (see the travel variable control dial for
more information).
Tamper Variable Control Dial: Used to control the
speed of the tamper bar. The tamper bar will stop
when the dial is turned to the off position (all the
way counterclockwise). The tamper bar will begin
to operate and increase speed as the dial is turned
clockwise. The tamper bar will decrease speed as the
dial is turned counterclockwise.
